Best 80W LED Moving head beam Factory Price - Yellow River
  • 商品详情

ElectricalVoltage100V ~240V,50-60HZ
Power consumption230W
Light SourceLED 80W White LED @5000lm/72000lux@5m
LED lifespan50000 hours
Control ModeDMX512√
Master/slave √
Auto√
RDM protocol√

Channelstandard mode 16CH/ extended mode 20 CH
Optical System           Strobe1~30t/s
CCT9800K
Color  wheel2 color wheels, 1color wheel includes: 11pcs color plates + CTO+ 1pc CTB plate + White open,semi-color effect, bi-direction flow effect. 1 pcs 6-color plate which can create a rainbow effect with prism.
Fixed Gobo Wheel9 gobos + 2 different size beam holes+ White open+gobo shake + bi-direction flow  effect
ScanScan:3-phase motor, Pan 540°/1.8s, Tilt 270°/0.9s, with photoelectric auto-reset and correction
 Prism

1 pc 8-facet prism

1 pc 16-facet prism, rotate independently, stackable to be 24 facets, bilateral rotation, bi-direction flow effect.

AngleAngle: beam  0.85°; with frost
Display1.4 -inch LCD color screen, can set the channel mode (standard model, extended mode), horizontal vertical inversion, screen reversible, signal hint, switchable in both Chinese and English, the automatic screen turn off / long last for display power on, display the channel number, source temperature, fan speed, record the power-on time, power on times, fault prosecution, manual control channel data memory, the software version information, restore factory Settings, the scanning, and the effect correction result.
Cooling systemCooling system: intelligent-temperature-control fan, fan stop when under 40℃, fan goes faster when over 40℃, every cooling board is made with mold, so it's accurate, efficient ventilation and noiseless.

safety protectionthe power will be cut off automatically  when the fixture is overheating or with a system error
Light source opening modesupport instant  blackout and lights on
Light body

1pc LCD display,

4pc buttons

power interface:1 in;1 out power;

signal interface: 3 pin + network/ 3pin+5 pin

Featured Effect1. High-efficiency cooling system, whole-process temperature monitoring.
2.2 color wheels, 1 pc 8-facet prism +1 pc 16-facet prismsemi-color effect, bi-direction flow  effect.
3. intelligent temperature-control fan,  timely display rotation speed.
Machine N.W11.4KG
Machine Size298*231*473mm
Environment& safetyLevel of ProtectionIP20
StockClean and dry place
Running temp.-10°C~40°C
