| Electrical | Voltage | Ac100v-240v (50/60hz) |
| Power consumption | 980w | |
| Power factor | 0.99 | |
| Rated current | 4.32a | |
| Light source | Lamp | 600w led module |
| Lamp life span | 20,000 hours | |
| Cct | 6300k | |
| Control mode | Control signal | Dmx512(digital multiplex 512)+rdm, in line with international standard light control transmission protocol, support console set address code, support dmx interface upgrade software |
| Control channels | 36 channels | |
| Operation mode | Console, manual, master-slave, optional dmx512 wireless signal control | |
| Optical system | Beam angle | 4.5° -50 ° |
| Dimmer | Linear dimming | |
| Color wheel | 7 high-gloss coating colors + white light, half-color effect, with two-way variable speed flow effect | |
| Cmy | An independent cmy color mixing system | |
| Prism | 8 prism +6 rows of mirrors, can be rotated independently, can be rotated bidirectional variable speed | |
| Cto | Independent 3200k-6300k color temperature linear adjustment | |
| Metal gobo | 8 patterns + white light, support replacement, with variable speed jitter, two-way variable speed flow effect | |
| Glass gobo | 7 patterns + white light holes, with rotation function, index function, two-way variable speed flow effect | |
| Effect wheel | 1 flame plate, can simulate the super dazzling sensation of moving flame effect | |
| Frost | 1 independent atomizer, 0-100% linear frost effect | |
| Environment& safty | Level of protection | Ip20 |
| Maximumtemperature | 40°c | |
| Overtemperature protection |
