Professional Beam+Wash+Spot Moving Head YR-380T for touring concert
- 商品详情
| Electrical | Voltage | 100V ~240V | |
| Power consumption | 550W | ||
| Light Source | Halogen lamp | 380W | |
| Lamp life span | 2000H | ||
| CCT | 7800K | ||
| Control Mode | DMX512 | 16 CH/24 CH | |
| Master/slave | √ | ||
| Auto | √ | ||
| RDM | √ | ||
| Optical System | Fixed Gobo Wheel 1 | 14 gobos+ white open + Shake + bi-direction flow effect,step change gobo; | |
| Rotation Gobo Wheel | 8 gobos + water wave glass + white open + bi-direction flow effect and rotation effect | ||
| Color wheel | 13color + White open + bi-direction flow effect+rainbow effect,change colors step by step; | ||
| Prism | 8 facet + 6 facett gradient prism, can be overlapped, can be rotated independently,bi-direction rotate effect | ||
| Shutter | 1~30t/s | ||
| Dimmer | 0-100% | ||
| Focus/Zoom | √ | ||
| Beam angle | 2.3° - 40 ° | ||
| X/Y scan | Three-phase motor, pan 540°,tilt:270°, photoelectric reset and correction | ||
| Display | 1pc screen touch display + 4pc buttons, LCD color screen, can set the channel mode, horizontal vertical inversion, back screen, signal hint, switch in both Chinese and English, automatic screen off/lasting bright screen, display channel number,record light source time, boot time and fault inspection, scene setting, the software version information, restore factory Settings | ||
| Signal interface | 3 pin | ||
| Power interface | 1 out powercon | ||
| Safety protection | the power will be cut off automatically when the fixture is overheating or with system error | ||
| Machine W. Size | kg mm | ||
| Environment& safty | Level of Protection | IP20 | |
| Stock | Clean and dry place | ||
| Running temp. | -10°C~40°C | ||
| 24CH | 16CH | ||
| 1 | 1 | Pan | |
| 2 | Pan fine-tuning | ||
| 3 | 2 | Tilt | |
| 4 | Tilt fine-tuning | ||
| 5 | 3 | Pan and tilt speed | |
| 6 | 4 | Function | |
| 7 | 5 | Color | |
| 8 | Color fine-tuning | ||
| 9 | 6 | Gobo | |
| 10 | 7 | Rotation Gobo | |
| 11 | 8 | Gobo self -rotate | |
| 12 | Self -rotate fine-tuning | ||
| 13 | 9 | Prism 1 | |
| 14 | 10 | Prism 1 self -rotate | |
| 15 | 11 | Prism 2 self -rotate | |
| 16 | 12 | Frost | |
| 17 | 13 | Zoom | |
| 18 | Zoom fine-tuning | ||
| 19 | 14 | focusing | |
| 20 | focusing fine-tuning | ||
| 21 | empty | ||
| 22 | 15 | Strobo | |
| 23 | 16 | Dimmer | |
| 24 | Dimmer fine-tuning | ||
| Item | Data | Unit qtn. | Accesssary for each | ||
| Packing Size W/Carton | cm | 1pc | 1 power cable 1 signal cable 1 suspender 1 user manual | ||
| Packing Weight W/CTN | kg | ||||
| Packing Size W/Fight Case | / | 2pcs | |||
| Packing Weight W/Fight Case | / | ||||
